Hikvision DS-2TD2628-10-QA Thermal and Optical Camera
The Hikvision HeatPro DS-2TD2628-10-QA is a professional bi-spectrum bullet camera designed to provide thermal and optical monitoring in commercial, industrial and outdoor environments. It combines a 256 × 192 thermal sensor with a 4MP optical camera, allowing users to monitor both heat patterns and visible scenes from one surveillance solution.
The thermal sensor uses a 12 μm VOx UFPA detector with NETD below 40 mK for sensitive thermal imaging. It can monitor temperatures from -20°C to 150°C with an accuracy of ±8°C, helping identify unusual temperature increases that may indicate a potential fire risk.
Early Fire and Temperature Detection
The camera is designed for applications where early detection of heat and fire-related events is important. Its temperature monitoring capabilities can identify temperature exceptions and provide alerts when configured thresholds are exceeded. This makes it suitable for warehouses, industrial facilities, construction areas and other locations where early warning can help protect property and equipment.
4MP Optical and Thermal Imaging
The combination of thermal and optical imaging provides two different views of the monitored scene. Thermal imaging helps identify heat sources, while the 4MP optical sensor provides visible details of people, vehicles and surrounding areas. This combination can improve situational awareness compared with relying on only one imaging technology.
Smoke and Fire Detection
The DS-2TD2628-10-QA supports a smoking detection algorithm designed to help identify smoke-related events. Along with temperature monitoring, this feature can provide an additional layer of detection for environments where early identification of possible fire events is important.
Intelligent Video Analysis
The camera supports video content analysis with human and vehicle classification. This can help distinguish people and vehicles from other movement in the scene and reduce unnecessary alerts. Advanced image processing features such as adaptive thermal AGC, DDE and 3D DNR further support clear thermal images in changing environmental conditions.
Durable Outdoor Construction
Built for demanding installations, the camera features IP67 weather protection and IK10 impact resistance. These ratings make it suitable for outdoor locations where the camera may be exposed to rain, dust or physical impact.
Key Features
- 4MP optical camera
- 256 × 192 thermal resolution
- 12 μm VOx UFPA thermal sensor
- NETD less than 40 mK
- Temperature detection from -20°C to 150°C
- ±8°C temperature accuracy
- Fire and temperature exception detection
- Smoking detection algorithm
- Human and vehicle classification
- Adaptive thermal AGC and DDE
- 3D digital noise reduction
- IP67 weather protection
- IK10 vandal resistance
- Bi-spectrum thermal and optical imaging
Ideal Applications
The Hikvision DS-2TD2628-10-QA can be used in warehouses, factories, construction sites, parking areas, industrial facilities and other locations where thermal monitoring and visible surveillance are required.
Professional Fire Prevention Monitoring
By combining thermal temperature detection, smoke detection and optical video analysis, this HeatPro bullet camera provides a practical surveillance solution for environments where early identification of unusual heat or possible fire activity is important.
Thermal and Optical Security in One Camera
The Hikvision HeatPro DS-2TD2628-10-QA brings thermal detection and 4MP visible imaging together in a durable bullet camera. Its intelligent analytics, temperature monitoring and outdoor protection make it suitable for professional surveillance installations requiring additional fire and heat monitoring capabilities.
