Hikvision Heat Pro DS-2TD2628T-7-QA 4mp BI-SPECTRUM Fire&smoke, Bullet Camera, 6.9mm, 6.4mm, Ir 30m

Hikvision HeatPro Thermal Fire Detection Camera

The Hikvision HeatPro DS-2TD2628T-7/QA is a professional bi-spectrum bullet camera designed to help detect fire risks, smoke and abnormal temperature changes at an early stage. It combines thermal imaging with an optical camera to provide useful visual information alongside temperature-based monitoring. This makes it suitable for industrial sites, warehouses, factories, storage areas and other locations where early fire detection is important.

The camera uses a 256 × 192 thermal sensor with 12 μm VOx UFPA technology and a NETD of less than 40 mK at 25°C. Its temperature measurement range extends from -20°C to 550°C, allowing the system to monitor heat changes across a wide range of applications. Temperature measurement accuracy is rated at ±2°C or ±2%, helping operators identify unusual heat levels.

4MP Optical and Thermal Imaging

The bi-spectrum design combines thermal detection with an optical imaging channel. The 4MP optical camera can provide visual details that complement thermal information, helping security teams better understand what is happening in the monitored area.

Early Fire and Smoke Detection

The DS-2TD2628T-7/QA supports dedicated fire and smoke detection functions. By monitoring temperature and visual conditions, it can help identify potential fire-related events at an early stage. Smoking detection is also supported, providing an additional monitoring function for selected environments.

Wide Temperature Measurement Range

The thermal channel can measure temperatures from -20°C to 550°C. This wide range allows the camera to monitor equipment, machinery, storage areas and other locations where unusual heat may indicate a developing problem.

Human and Vehicle Classification

Advanced video content analysis helps classify people and vehicles. This can improve event filtering by distinguishing different types of movement and helping reduce unnecessary alerts in busy industrial environments.

Smart Filtering for Industrial Areas

Industrial locations can create challenging conditions for intelligent detection systems. The camera includes a sun-reflection filter and forklift alarm filter to help reduce unwanted alerts caused by common activities and environmental conditions.

Advanced Thermal Image Processing

The camera supports linear, histogram and self-adaptive thermal AGC modes for improved thermal image presentation. DDE and 3D DNR technologies further support image clarity and noise reduction, helping operators monitor thermal events more effectively.

Professional Fire Prevention and Security

The Hikvision HeatPro DS-2TD2628T-7/QA combines thermal measurement, optical imaging, fire detection, smoke detection and intelligent video analysis in one surveillance solution. Its combination of temperature monitoring and visual verification makes it suitable for demanding commercial and industrial security applications.

Key Features

1. 4MP optical imaging
2. 256 × 192 thermal resolution
3. 12 μm VOx UFPA thermal sensor
4. NETD less than 40 mK at 25°C
5. Temperature measurement from -20°C to 550°C
6. Temperature accuracy of ±2°C or ±2%
7. Fire detection support
8. Smoke detection support
9. Smoking detection support
10. Human and vehicle classification
11. Sun-reflection filter
12. Forklift alarm filter
13. Linear, histogram and self-adaptive thermal AGC
14. DDE and 3D DNR
15. Bi-spectrum thermal and optical imaging

Suitable Applications

This thermal bullet camera can be used in factories, warehouses, industrial facilities, equipment monitoring areas, storage facilities, critical infrastructure and other locations where early identification of heat anomalies, fire or smoke is required.

Smart Thermal Monitoring

The combination of thermal temperature measurement and optical video allows users to investigate potential events with more useful visual information. This makes the camera suitable for applications where traditional CCTV alone may not provide enough information about developing heat-related risks.

Reliable Monitoring for Fire Prevention

With its thermal sensor, wide temperature measurement range, fire and smoke detection capabilities and intelligent filtering functions, the DS-2TD2628T-7/QA provides a dedicated solution for monitoring demanding environments and identifying potential hazards before they develop into larger incidents.
