Hikvision HM-TD6368-50C4L/G0/T2Y Thermal + Optical PTZ

Hikvision  Thermal & Optical PTZ Camera

The Hikvision HM-TD6368-50C4L/G0/T2Y is a high-performance thermal and optical bi-spectrum PTZ camera designed for long-distance surveillance, fire monitoring and perimeter protection. It combines a 640 × 512 thermal sensor, 50mm thermal lens, and 4MP optical camera with 56× optical zoom to provide reliable monitoring across large outdoor areas.

Long-Range Thermal Imaging

The 640 × 512 thermal imaging channel detects heat signatures in darkness, poor visibility and challenging weather conditions. Its 50mm thermal lens is designed for long-range monitoring, making the camera suitable for industrial facilities, mining areas, substations, ports, solar farms and other large sites.

Early Fire and Smoke Detection

The camera is designed to support early fire monitoring across extensive areas. Under suitable conditions, it can detect a reference 1m × 1m fire target from approximately 2,000m and a reference 5m × 5m smoke target from up to approximately 6,000m. Up to 10 fire points can be dynamically identified, helping operators respond to potential incidents at an early stage.

4MP Optical Camera with 56× Zoom

Alongside thermal imaging, the optical channel delivers detailed visible-light video for target verification and identification. With 56× optical zoom, operators can inspect distant objects, people, vehicles and potential incidents without needing to move closer to the monitored area.

2,000m Laser Illumination

The integrated laser illumination can reach up to approximately 2,000m, supporting long-range optical monitoring at night and in low-light environments. This makes the system useful for remote sites where conventional lighting may not provide sufficient coverage.

360° PTZ Surveillance and Intelligent Analytics

The PTZ mechanism supports continuous 360° pan movement for broad-area monitoring. Intelligent analytics can assist with intrusion detection, line crossing, region entrance and region exit detection, as well as long-range human and vehicle monitoring.

The Hikvision HM-TD6368-50C4L/G0/T2Y is well suited to large-scale applications where thermal detection, optical verification and long-range PTZ surveillance are required from a single integrated system. It can be used for critical infrastructure, mining operations, industrial sites, waste facilities, ports, solar farms, substations, stockpiles and remote perimeter security.
