Hikvision DS-2TD2117-10/QA | DeepInView Thermal Bullet Camera | 160×120 | 10mm | IP66 The DS-2TD2117-10/QA delivers a high-sensitivity thermal image

Hikvision DS-2TD2117-10/QA 160×120 Thermal Camera

The Hikvision DS-2TD2117-10/QA is a professional DeepInView thermal bullet camera designed for reliable perimeter protection, industrial monitoring and early fire detection. Using a high-sensitivity thermal sensor with a 160×120 resolution and 10mm lens, the camera can detect heat and activity in challenging lighting conditions where conventional optical cameras may have limitations.

With a NETD of less than 40mK at 25°C, the camera is designed to identify small differences in temperature and provide useful thermal imagery. This makes it suitable for monitoring industrial sites, construction areas, infrastructure facilities, factories and other locations that require continuous outdoor surveillance.

Deep Learning Detection

The built-in GPU supports deep learning algorithms for advanced video content analysis. The camera can detect events such as line crossing, intrusion and region entrance or exit. These intelligent detection functions can help security teams monitor defined areas and respond to potential security events more efficiently.

Thermal Fire Detection

One of the key features of the DS-2TD2117-10/QA is its thermal fire detection capability. The camera can monitor temperature changes and provide temperature-anomaly alarms when unusual heat levels are detected. Its fire detection algorithm can support early warning in environments where overheating or fire presents a significant risk.

Advanced Thermal Image Processing

The camera uses Adaptive AGC, DDE and 3D DNR technologies to improve thermal image quality. These image processing features help produce clearer and more usable thermal images across different environmental conditions.

Multiple Colour Palettes

Operators can select from up to 15 adjustable colour palettes according to their monitoring requirements. Contrast adjustment also allows users to customise the thermal display and make temperature differences easier to observe.

Active Alarm and Deterrence

The camera supports active alarm functions including a strobe light and audio alarm. When a configured detection event occurs, these features can provide an immediate visual and audible warning to help deter unwanted activity.

IP66 Outdoor Protection

The Hikvision DS-2TD2117-10/QA is designed for outdoor deployment and carries an IP66 protection rating. This makes it suitable for applications where the camera needs protection from dust and water exposure.

Key Features

1. 160×120 thermal resolution
2. 10mm thermal lens
3. Up to 25fps
4. NETD less than 40mK at 25°C
5. Deep learning VCA detection
6. Line crossing and intrusion detection
7. Region entrance and exit detection
8. Temperature-anomaly alarm
9. Advanced fire detection
10. Adaptive AGC and DDE
11. 3D DNR image processing
12. Up to 15 colour palettes
13. Strobe light and audio alarm
14. IP66 outdoor protection

Suitable Applications

The camera is suitable for factories, construction sites, industrial facilities, critical infrastructure, perimeter security, warehouses and other locations where thermal monitoring and early hazard detection are important.

Professional Thermal Surveillance

The DS-2TD2117-10/QA combines thermal imaging, intelligent detection and fire monitoring in a compact bullet camera. Its thermal technology allows security teams to monitor heat patterns and potential threats even when visible-light conditions are poor.

Reliable Monitoring for Security and Fire Detection

With thermal imaging, deep learning analytics, temperature alarms, fire detection and active deterrence features, the Hikvision DS-2TD2117-10/QA provides a versatile surveillance solution for demanding commercial and industrial environments.
