Hikvision DS-K1T502DBWX-C Access Control Terminal Keypad with Camera & Intercom

Hikvision DS-K1T502DBWX-C Access Control Terminal

The Hikvision DS-K1T502DBWX-C is a versatile access control terminal designed to combine secure entry management, video intercom and communication functions in one compact device. With a built-in camera, keypad and multiple authentication options, it provides a practical solution for offices, commercial buildings, residential properties and other controlled access areas.

Secure Access Control

The terminal supports several authentication methods, including PIN and card access, giving users flexible ways to enter a protected area. It can also connect to an external access controller through the Wiegand protocol, making it suitable for integration with existing access control systems.

The device supports PIN configuration in both platform and local modes, allowing access settings to be managed according to the requirements of the installation.

Built for Indoor and Outdoor Use

The DS-K1T502DBWX-C is constructed with zinc alloy materials to provide a strong and durable enclosure. Its IP65 protection helps protect the terminal against dust and water, while IK09 impact protection provides additional resistance against physical impact.

This combination makes the terminal suitable for demanding access points where durability and reliable operation are important.

Integrated Video Intercom

The built-in camera and video intercom capabilities allow the terminal to provide more than simple door access. It supports SIP-based video intercom communication and can work with supported SIP servers such as Brekeke, miniSipServer, FreePBX, Asterisk, 3CX, ELASTIX and PBXware.

When the calling button is pressed, the device can call a management center, indoor station, specified indoor station or the Hik-Connect App, depending on the configured system.

Flexible Connectivity

The terminal provides several communication options for system integration. RS-485 communication can be used to connect an external card reader or support elevator-related applications. It also supports Wiegand connectivity for connection with compatible external access controllers.

The device also supports AP mode, providing additional flexibility during network configuration and deployment.

Network Management

Network configuration can be adapted to different installation requirements. The system allows administrators to set the priority between wired and wireless network connections, helping provide a suitable communication path for the access control system.

Local Storage Support

For applications that require local storage, the DS-K1T502DBWX-C supports a microSD card with capacity of up to 256 GB. This provides additional storage flexibility depending on the configured system and application requirements.

Important Power Requirement

Please note that the Hikvision DS-K1T502DBWX-C is not a PoE device. It requires a separate 12 VDC to 24 VDC / 1 A power supply. Make sure the appropriate power source is available before installation.

A Practical Access Control Solution

With its keypad, camera, card authentication, video intercom, network connectivity and durable construction, the Hikvision DS-K1T502DBWX-C provides a flexible solution for modern access management. Its support for external readers, controllers, indoor stations and SIP communication also makes it suitable for installations that require integration with wider security and communication systems.
