Hikvision Bi-Spectrum Driving Assistance System
The Hikvision DS-2TV13-10I is a vehicle-mounted thermal and optical bi-spectrum driving assistance system designed to improve visibility and situational awareness in demanding driving environments. By combining thermal imaging with optical video, the system gives drivers a clearer view of surrounding conditions, particularly when darkness, fog, dust, smoke, or other low-visibility conditions make conventional viewing more difficult.
With a 384×288 high-sensitivity thermal sensor and a NETD of less than 40 mK at 25°C, the system is designed to detect heat differences and provide detailed thermal imagery. This makes it suitable for applications where identifying people, vehicles, obstacles, or other objects at night is important.
384×288 High-Sensitivity Thermal Imaging
The integrated thermal sensor provides 384×288 resolution for monitoring heat signatures in challenging environments. Its NETD of less than 40 mK at 25°C supports sensitivity to small temperature differences, helping produce clearer thermal images during nighttime and other difficult visibility conditions.
Bi-Spectrum Image Fusion
The DS-2TV13-10I combines thermal and optical imagery through bi-spectrum image fusion technology. Bringing both image sources together helps provide additional visual information from a single system, allowing drivers to better understand their surroundings without depending only on standard visible-light imaging.
Advanced Thermal Image Processing
The system incorporates several thermal image processing technologies, including Adaptive AGC, DDE, and 3D DNR. These technologies help optimise image presentation and reduce unwanted noise, supporting clearer thermal viewing in different environmental conditions.
Shutterless Thermal Technology
Shutterless technology helps provide continuous thermal imaging without regular mechanical shutter interruptions. This can support a smoother viewing experience for vehicle operators who require uninterrupted awareness while driving or monitoring an area.
800×480 LCD Display
An integrated 800×480 LCD display provides a dedicated viewing interface inside the vehicle. Drivers can view the available thermal and optical imagery directly from the cab, helping them monitor the road and surrounding environment without relying solely on external visibility.
Built for Demanding Vehicle Applications
The DS-2TV13-10I is designed for vehicle-mounted applications where dependable operation is important. Intelligent de-icing helps maintain the viewing window in cold conditions, while the replaceable IR window provides a practical maintenance feature.
IP67 Weather Protection
With an IP67-rated design, the system is protected against dust and water exposure, making it suitable for demanding outdoor vehicle environments.
Key Features
- 384×288 high-sensitivity thermal imaging
- NETD less than 40 mK at 25°C
- Thermal and optical bi-spectrum image fusion
- Adaptive AGC, DDE and 3D DNR processing
- Shutterless thermal imaging technology
- 800×480 LCD display
- Intelligent de-icing function
- Replaceable IR window
- IP67 weather protection
- Designed for vehicle-mounted driving assistance
