Hikvision DS-2TD2617-6/QA Thermal HeatPro Cameras Dual lens 6mm

Hikvision  Thermal HeatPro Camera

The Hikvision DS-2TD2617-6/QA is a professional dual-lens thermal camera designed for reliable perimeter protection, fire detection, and temperature monitoring. It combines thermal imaging with an optical channel to provide better awareness of heat sources and visible surroundings in a single surveillance solution. The camera can detect thermal information in complete darkness, making it suitable for applications where conventional cameras may struggle.

It features a 160 × 120 VOx UFPA thermal detector with a 17 μm pixel pitch and a 6mm focal length. With NETD below 40 mK, the thermal sensor is designed to provide high sensitivity when identifying differences in temperature. This makes the camera useful for monitoring outdoor boundaries, industrial areas, equipment and other locations where heat detection is important.

Dual-Lens Thermal and Optical Imaging

The dual-lens configuration combines thermal and visible-light imaging in one camera. Thermal imaging helps identify heat signatures, while the optical channel provides additional visual information about the monitored area. This combination can help security teams investigate events more effectively.

Temperature Measurement and Exception Alarms

The camera supports temperature monitoring from -20°C to 150°C with an accuracy of ±8°C. Temperature exception alarming can be used to identify unusual heat levels and generate alerts when configured temperature conditions are detected. This feature is useful for industrial monitoring and fire prevention applications.

160 × 120 Thermal Resolution

The 160 × 120 thermal detector provides dedicated heat-based imaging that does not depend on visible light. With a 17 μm pixel pitch and NETD below 40 mK, the sensor is designed for sensitive thermal monitoring across different environmental conditions.

Advanced Thermal Image Processing

The DS-2TD2617-6/QA supports multiple thermal AGC modes, including linear, histogram and self-adaptive modes. DDE and 3D DNR technologies further help improve thermal image presentation by enhancing details and reducing unwanted noise.

Reliable Outdoor Protection

Designed for outdoor deployment, the camera has an IP67-rated housing to provide protection against dust and water. This makes it suitable for continuous monitoring in demanding environments where equipment may be exposed to changing weather conditions.

Perimeter Protection and Fire Detection

Thermal surveillance can help detect heat signatures that may not be easily visible through standard video alone. The DS-2TD2617-6/QA can be used for perimeter monitoring, industrial sites, restricted areas and fire-risk locations where early detection of unusual heat can support faster response.

Key Features

1. Hikvision HeatPro dual-lens thermal camera
2. 160 × 120 VOx UFPA thermal resolution
3. 17 μm pixel pitch
4. 6mm focal length
5. NETD below 40 mK
6. Thermal and optical imaging channels
7. Temperature measurement from -20°C to 150°C
8. ±8°C temperature measurement accuracy
9. Temperature exception alarming
10. Linear, histogram and self-adaptive thermal AGC
11. DDE and 3D DNR image processing
12. IP67 weatherproof protection
13. Designed for perimeter protection and fire detection

Suitable Applications

The Hikvision DS-2TD2617-6/QA can be used at industrial facilities, warehouses, perimeter boundaries, critical infrastructure sites, restricted areas and locations where fire or abnormal temperature detection is required.

Thermal Monitoring in Complete Darkness

Unlike conventional cameras that depend on visible light, thermal imaging detects heat signatures. This allows the camera to continue providing thermal information during darkness and in challenging visibility conditions.

Professional Thermal Security Solution

The DS-2TD2617-6/QA provides a practical combination of thermal detection, visible imaging, temperature monitoring and outdoor protection. Its dual-lens design and HeatPro features make it suitable for professional surveillance installations where reliable thermal information is an important part of security monitoring.
